ROCKET BOOMER M2C

Standard features »Rock drill

• COP 1638, COP 1838 or COP 2238 rock drill with dual-damping system for optimal consumable life

• Pressurized housing and mating surfaces to reduce internal contamination of the rock drill »Hydraulic boom

• BUT 35 SL heavy-duty boom with double tripod suspension for accurate hydraulic parallel holding in all directions »Hydraulic feed

• BMH 6000-series heavy-duty aluminium feed with high bending and torsional resistance for maximum durability

• Snap-on stainless steel sleeves and polymer contacts

»Control system • Advanced Rig Control System (RCS) allowing several levels of automation to suit customer requirements

• Standard functions include soft collaring and the anti-jamming function Rotation Pressure Controlled Feed (RPCF) • Integrated diagnostic and event logging system to assist in equipment maintenance

• Interactive operator panel with full-colour display »Carrier

• Sturdy, articulated carrier with four-wheel drive

• Powered by a 4-cylinder, EPA III/COM III (Tier 3/Stage IIIA) approved diesel engine

• Four jacks for stable set up »General

• FOPS-approved telescopic protective roof

• Cable reel

• Hydraulically driven compressor

• Hydraulically driven water booster pump.
